Network system\tGSM 900 / GSM 1800 / GSM 1900
Size\t134 x 70 x 20 mm, 139 cc
Weight\t137 g
Display\t- TFT, 4096 colors
- 176 x 208 pixels
- Five-way directional controller
Battery type \tStandard battery, Li-Ion 850 mAh
Stand-by\tUp to 200 h
Talk time\tUp to 4 h
Ringtones\t
Option\t- Slave USB 1.1. port
- Stereo line-in
- Polyphonic ring tones
- MP3, AAC, Midi, WAV ringing tones
- Mono ringtone composer
- Photo phonebook
- Build-in handsfree/speaker
- Hi-fi stereo headset
Number in phone\t8 fields, shared memory
Call records\tAll for the last month, adjustable
Memory\t- 3.4 MB shared internal memory
- MMC card slot
- Shared memory for images, contact data, calendar, messages, add-on applications
- 20 voice dial numbers
GPRS\tClass 4 (3+1 slots)
Messaging\tSMS, MMS, Email
Infrared port\t
Games\tTons, single and multiplayer
Color\t
Features\t- Symbian OS with Java support
- Bluetooth
- MP3 and AAC player
- Stereo FM radio
- WAP 2.0
- xHTML browser with iMode
- HSCSD
- T9
- SyncML
- Voice dial

Network system\tGSM 900 / GSM 1800
Size\t118 x 68 x 22 mm, 123 cc
Weight\t143 g
Display\t- TFT, 4096 colors
176 x 208 pixels
- Four-way directional controller
Battery type \tSlim battery, Li-Ion 1070 mAh
Stand-by\tUp to 240 h
Talk time\tUp to 3 h 30 min
Ringtones\t
Option\t- Polyphonic ring tones
- Midi, WAV ringing tones
- Mono ringtone composer
- Photo phonebook
- Build-in handsfree/speaker
- Hi-fi stereo headset
Number in phone\t8 fields, shared memory
Call records\tAll for the last month, adjustable
Memory\t- 3.4 MB shared internal memory
- MMC card slot, Hot swap
- Shared memory for images, contact data, calendar, messages, add-on applications
- 20 voice dial numbers
GPRS\tClass 6 (3+1/2+2 slots)
Messaging\tSMS, MMS, Email, Instant Messaging
Infrared port\tNo
Games\tTons, single and multiplayer
Color\t
Features\t- Symbian OS, Series 60 UI
- Java
- Bluetooth
- WAP 2.0
- xHTML
- HSCSD
- T9
- SyncML
- Voice dial

http://www.indowebster.com/NGAGE_Classic_Schematic_Uploaded_By_s00ny.html

http://www.indowebster.com/NGAGE_QD_Schematic_Uploaded_By_s00ny.html
