Camera Optics
Lens Type: Fixed Focus (2ft/.6m – ∞, glass
Aperture: f/2.8 (high performance in low-light situations)
Angle of View: 170º ultra wide angle in WVGA, 720p, or 960p mode
Angle of View: 127º wide angle in 1080p mode
Video
HD Video Resolution Modes: (subject to change, pending final firmware release)
1080p = 1920×1080 pixels (16:9), 30 fps, 15 Mbit/s data rate
960p = 1280×960 pixels (4:3), 30 fps, 12 Mbit/s data rate
720p = 1280×720 pixels (16:9), 60 fps, 15 Mbit/s data rate
720p = 1280×720 pixels (16:9), 30 fps, 8 Mbit/s data rate
WVGA = 848×480 pixels (16:9), 60 fps, 8 Mbit/s data rate
Sensor Type: 1/2.5″ HD CMOS, 2.2µm-sized pixels
Light Sensitivity: Super low-light sensitivity (>1.4 V/lux-sec)
Video Format: H.264 compression, saved as Windows- & Mac-compatible MPEG4 (.mp4) file
Exposure Control: Auto with user selectable center weighted average and spot metering settings
White Balance: Auto
Audio
Microphone: Built-in, mono with AGC (automatic gain control)
Audio Format: 48 kHz, AAC audio compression
Resolution: 5 megapixel
Capture Modes: Single shot, photo every 2, 5, 10, 30 or 60 secs.; 3 photo burst; self-timer
Storage
Memory: SD card (SDHC), up to 32GB capacity (not included)
Average recording times (using 32GB SD card):
1080p (30 fps): 4h 21m
960p (30 fps): 5h 26m
720p (60 fps): 4h 21
720p (30 fps): 8h 09m
WVGA (60 fps): 8h 09m
Connectors & Cables
PC Connection: USB 2.0 (data connection and battery charging)
HDTV Out: HD NTSC & PAL (component cable incl.)
Audio Out: Combo 2.5mm jack with stereo audio and composite video out
PC Compatibility: Windows® Vista or Windows® 7; Mac OS® X 10.4.11 and later
Power & Battery
Battery Type: Rechargeable 1100 mAh lithium-ion
Battery Life: Approx. 2.5 hrs
Charging: via USB to computer or optional power adapter
Charge Time: 80% capacity after 1 hour with optional power adapter; or 2 hours with a computer’s USB port
Waterproof Camera Housing
Depth Rating: Up to 180 feet / 60 meters
Construction: Polycarbonate and stainless steel
Hardware: Stainless steel
Size & Weight
Dimensions (H x W x D): 1.6” x 2.4” x 1.2” (42mm x 60mm x 30mm)
Weight: 3.3oz (94g) incl. battery, 5.9oz (167g) incl. housing

Camera Optics

2X Sharper Professional Glass Lens
f/2.8 Fixed Focus
170º Wide FOV (Including 1080p)
127º Medium FOV (In 1080p)
90º Narrow FOV
Video

HD RESOLUTIONS:
1080p: 1920×1080, 30FPS
960p: 1280×960, 48FPS + 30FPS
720p: 1280×720, 60FPS + 30FPS
STANDARD DEFINITION RESOLUTIONS
WVGA: 848×480, 120FPS + 60FPS
High Performance,1 /2.3” CMOS Image Sensor
Light Sensitivity: .84 V/lux-sec
Video Format: H.264 codec, .mp4 File Format
Exposure Control: Spot, Center Weighted
White Balance: Auto

RESOLUTIONS: 11MP, 8MP, 5 MP
FOV: Wide 170º FOV, Medium 127º FOV
CAPTURE MODES: Single, 10 Photo Burst, Time-Lapse*, Self-Timer
* Now supports time-lapse photo every 0.5 seconds. Requires Class 10 speed SD Card.
Audio

Mono, 48 kHz, AAC Compression, Auto Gain Control
Stereo External Microphone Input (3.5mm)
Storage

MEMORY:
SDHC: Up to 32GB (Class 4 or Higher)
AVERAGE RECORDING TIME WITH 32GB SD CARD:
1080p30: 4 hours
960p30: 6 hours
720p60: 4 hours
720p30: 6 hours
WVGA 120: 4.5 hours
Included Cables

USB Cable For Charging and Data Transfer
Battery & Charging

1100mah Rechargeable Lithium-Ion
Charge via USB
Operating System

Microsoft Windows® Vista, 7 and Later
Mac OS® x 10.5 and Later
Compatible with all GoPro BacPacs

Wi-Fi BacPac™ and Wi-Fi Remote™ (Coming Soon)
LCD BacPac™
Battery BacPac™
3D HERO® System*
