Thread ini dibuat bagi teman2 yang Menggunakan / pernah menggunakan Mercedes benz New Eyes W210 , monggo gabung dan sharing pengalaman suka & duka selama pelihara W210, baik itu kelebihan maupun kekurangannya , serta masalah yang kerap terjadi. Dikarenakan usianya yang semakin "uzur" dan tentunya dapat disertakan tips2 solusi tentang problem dari W210 tsb.
W210 terbagi menjadi beberapa varian baik itu PreFacelift , Facelift dan Staton Wagon dengan rentang waktu produksi 1996 s/d 2002 , kapasitas mesin juga terbagi menjadi beberapa model/type, antara lain e200 , e230 , e240 , e260 , e320 , e430 , e500 , e55 amg dan Versi diesel
W210 Engine
This was the first time a V6 engine was offered (model year 1998) to replace the straight-six configuration (1996–1997). This new Mercedes-Benz M112 engine produced 221 hp (164 kW) and 229 ft·lbf (310 N·m) of torque and offered a 0-60 mph (98 km/h) of 6.9 seconds. Other offerings were the E420 (1997), E430 (1998–2002), and E55 AMG (1999–2002) with 354 hp (264 kW) and a 5.4 L normally aspirated engine. In North America, the range also features two diesels, including both non-turbocharged (1996–1997) and turbocharged (1998–1999) 3.0 litre straight-six units. In 2000, Mercedes-Benz discontinued diesel powerplants in the E-class in North America. In Europe, the diesel engines were superseded by more advanced Common Rail (CDI) units (2000–2002). The CDI engines were not offered in North America until the E320 CDI in the newer W211 model. (WIKIPEDIA)
Reliability Concern
Reliability concerns
Some known problems include the front spring perch has corroded and tearing away from the inner fender (wing), causing the front suspension to collapse. (4Matic models are not believed to be affected.) Other problems include defective harmonic balancer pulleys (recall), rust on trunk lid near latch, rust on Mercedes emblem on front hood, rust on door frames under window seals (recall), rust on front wings just above bumper, defective mass airflow meter, melted rear light bulb sockets, defective blower motor regulators, and rear window regulator failures.
Harmonic Balancer - Some M112 and M113 engines used in W210 models were equipped with a harmonic balancer pulley which, due to a supplier quality problem, may fail and cause engine damage. If the rubber insert of the harmonic balancer pulley delaminates, the pulley may grind through the timing chain cover and oil pan, causing several thousand dollars of damage. Mercedes-Benz USA issued Service Campaign #2005-020003[17] which included inspection of the part and replacement if necessary at no cost. The part number on the harmonic balancer pulley can be compared to those given to Mercedes-Benz dealers in the Service Campaign notice[18] to determine if the part is a faulty original or has been replaced with the updated part. Replacement of the faulty part with the updated part should be a permanent solution to this problem.
Blower Motor Regulator - If this part fails, the climate control fan will not operate faster than approximately 50% power. Mercedes updated the regulator to improve its reliability, but the redesigned regulator requires the installation of a new blower motor—about $1,000 in parts. The old-style regulator, which is compatible with the existing blower motor, is no longer manufactured. The blower motor regulator may be replaced with the much less expensive W140 S-class blower regulator, provided that the E-class wiring harness is re-attached to the S-class regulator.[19]
Front Sway Bar Drop Links - While not a serious concern, most E-classes end up with a sub 35 mph (56 km/h) clicking or rattling sound from the front end. This is usually due to worn out front-end sway-bar drop links. These can easily be replaced by anybody with minor knowledge of vehicle DIY, for no more than around £20.[20]
Front Spring Perches - Some owners have reported rust problems on the front spring perches - the top perches, which hold the tops of the springs for the front suspension. The perches are spot welded to the chassis, and factory coated in a weatherproof mastic to stop their rusting, however in some rare occurrences, water gets behind the mastic causing the perches to rust and eventually to fail - leading to collapse of the suspension. The car remains controllable. This is a problem that Mercedes USA have acknowledged. The problem is not identifiable without first removing the mastic to check.
Body corrosion - Most model year versions of the W210 displayed body rust, notably on European-sold cars. Rust would sometimes appear spontaneously on panels such as doors and roofs on cars less than a year old. In response to this problem, the manufacturer would normally change or repair the affected panels under warranty.[21] Mercedes-Benz has been criticized in the European press for not officially acknowledging this problem. This was due to problems introducing water based paint technology.
Window regulators - The power window regulator, essentially the mechanism that transfers power from the electric motor to the window, has a few plastic parts that can fail after several years causing the power window to stop operating. DIY replacement of a window regulator can be done in about 1–2 hours at a cost of somewhere between $60 and $120 for the part.[22]
Head Gasket - The head gasket on the M104 is known to fail, causing an oil leak at the rear of the cylinder head.[citation needed]
Differential Bushing - The rear IRS differential bushing wears rapidly during high performance driving and cornering.[citation needed]
Diesel injection distributor pump - The OM604 engines (E200D and E220D) were equipped with an electronically controlled injection pump from Lucas. The seals of the Lucas injection pumps become brittle over time and leak. The electromechanics have also been know to fail. Since the replacement of the entire injection pump is very expensive, a repair kit is offered in which the affected seals are replaced. Failed Lucas pumps are also commonly replaced with Bosch pumps from W124. (WIKIPEDIA)
suspension
Suspension
- Front Independent double wishbone with coil springs, gas-pressurized shock absorbers and stabilizer bar.
- Rear 5-arm multilink with coil springs, gas-pressurized shock absorbers and stabilizer bar.
- Brakes Hydraulic dual-circuit braking system with vacuum servo unit, disk brakes, internally ventilated, two piece front "floating" rotors and 4-piston front calipers.
Thread ini bukanlah sebuah klub otomotif, tetapi merupakan sebuah wadah untuk bertukar pikiran bagi para pecinta/penikmat New Eyes , sekaligus juga merupakan ajang silahturahmi untuk menjalin kekerabatan dan kebersamaan dgn para pengguna W210
Quote:Original Posted By louwyne► Mlm sy lg cari shifter modul buat w210 2001 mungkin ad yg tau cari copotan yg harga ny bgs dmn?ketumpahan air..jd error skrng posisi gigi d D msk 1 ga mau pindah2..
Kalo gak salah temen punya, tapi harus tau part number kalo mau bener.
Sy sudah ganti part ny..cmn msh sama msh ga mau ganti dr D diem di gigi 1.. ap pengantian part gt harus reset dl? Or mungkin part yg sy ganti rusak jg ?
Quote:Original Posted By louwyne► Sy sudah ganti part ny..cmn msh sama msh ga mau ganti dr D diem di gigi 1.. ap pengantian part gt harus reset dl? Or mungkin part yg sy ganti rusak jg ?
mohon tanya suhu2.. punya w210 e260. lokal. climate control manual. pengen rubah single din ke double din dengan modif potong kayu faceplate. denger2 tukang audio. kalo tempat kotak yg di bawah head unit. dalamnya lebih pendek dari pada dalam headunitnya.maka double dinnya harus beli yg non cd (lebih p3ndek). apakah benar? mohon di confirmasi.
ya. ngaco sih om. habisnya... yg wood trim double din yg manual climate control ga pernah nemu sih.. jadi mau ga mau.. lagipula wood trim std di ebay banyak banget... kalo mau di standarin lagi. tinggal plug n play...
Quote:Original Posted By gilajuga► ya. ngaco sih om. habisnya... yg wood trim double din yg manual climate control ga pernah nemu sih.. jadi mau ga mau.. lagipula wood trim std di ebay banyak banget... kalo mau di standarin lagi. tinggal plug n play...
Ngaco donk, harusnya instead of motong ori, mending bikin kayu baru dari atas sekalian.
Kan jadi aneh juga ada garis.
4 bulan terakhir Saya masih nyari W210, cuma Bingung mau ambil yang in Line biasa atau V6, ngerawatnya enakan yang mana ya, ane user E36 M43 sebelumnya, lagi mau ngumpulin besi tua German om hehehe
- penyakitnya apa aja ya
- Bensin gmana (AT) kaki ane sekolah oM
- Spare parts
- Bengkel jujur di Bekasi
Belum ketemu yang price performance mint condition
Quote:Original Posted By pdgang► Bikin wood yang baru aja mas. Gak mahal juga kalo bikin. Sayang kalo yang ori dirusak. Kalo mas beli wood double din standar yang udah jadi, juga beda lobangnya sama head unit model sekarang, jadi nanti kerja dua kali. Jadi mendingan bikin woodnya.
Quote:Original Posted By ....A....► 4 bulan terakhir Saya masih nyari W210, cuma Bingung mau ambil yang in Line biasa atau V6, ngerawatnya enakan yang mana ya, ane user E36 M43 sebelumnya, lagi mau ngumpulin besi tua German om hehehe
- penyakitnya apa aja ya
- Bensin gmana (AT) kaki ane sekolah oM
- Spare parts
- Bengkel jujur di Bekasi
Belum ketemu yang price performance mint condition
Tidak ada penyakit selama beli barang bagus, bukan barang murahan.
I6 bisa masuk 1: 6/7.
V6 bisa masuk 1: 9.
Parts merem juga dapet, banyak.
Quote:Original Posted By keronians► Iya gan, udah di tune up macem macem malah jadi boros kayak gitu, padahal mesin aman 😢 press selang power steering sendiri kira kira gimana ya gan? Cari cari sampe Aliexpress kagak nemu juga
Airmasd sensor, stelan co pada bagus gak?
Selang power steering kayaknya gak sesulit itu deh cari, masa sampe harus aliexpress yang notabene barang biasa.
Quote:Original Posted By keronians► Airmass normal gan, tapi setel Co ini rencananya baru mau di bawa ke Bandar Lampung sekalian coba reset modul dan ECU di mobil. cuma baru mau berangkat, eh selang PS pecah oh iya, partsnya udah temu di Ebay mbah, tapi untuk E320, gak tau sama atau enggak
Btw gan, alternatif kalau gak ada Stardiag gimana ya untuk scan dan reset komputer di W210?
SD itu sama aja, tinggal mekanik ngerti apa gak cara baca SD
om mau nanya ane pengguna NE
kalau lagi muter balik kadang stir nya ga ngebalik itu kira kira apa ya?
apa pengaruh velg? ane pake ring 18 sma sportkit ban 235
di sini yang pake NE pada pake W atu S aja ya biasa nya?
matur nuhun
